Wenglor
Retro Reflex Sensors
Fully encapsulated
Integrated Logic
Large working Range
Recognition of high-gloss and jet black objects

Electrical data :
Power supply : 18 ... 30 vdc
Power consumption sensor : 35mA
Switching frequency : 100Hz
Response time : 5 ms
Temperature drift :  10%
Temperature range :  -15 .... 50 C
Switching out put : 1
Switching out put voltage drop : < 2.5 V
PNP switching outputs / switching current : 400mA
Short circuit protection : yes
Reverse polarity protection : yes
Overload protection : yes
Logic : yes
Block discharge : yes
Valve control : yes

Mechanical data :
Housing : plastic
Fully encapsuled : yes
Protection mode : IP 65
Connection : M 12x1

Type : OPT162, XN96VBH3, XN96VDH3, XN96TBH3, XN96TDH3, XD100PA3, XD100NA3, XW100PA3, XW100NA3, XM98PAH2, XM98PDVH2, XM98NDH2, RO88PB3, RO88PD3, RO88ND3, LK88PB8, LK88PD8, LK88NB8, LK88ND8, LK88PB, LK88PD, LN89PA3, LN89PDV3, LN89NA3, LN89PA3, LD86PVC, LN40PA3, LN40NA3, LN40PA, KN88PA3, KN88PDV3, KN88NA3, KN88PA, KR87PCT2, KR87NCT2, LD86PA3, LD86PCV3, LD86PCT3, LD86NCT3, LW86PA3, LW86PC3, LW86PCV3, LW86PCT3, LW86NCT3, LM89PA2, LM89PVC2, LM89PCT2, LM89NCT2, LM89PA, XR96PCT2, XR96NCT2
