Part No.:
425.120.75
Connection:
screwable connection with wire protection max. 1.5 mm² finely stranded
Fixing:
Bracket mounting
Flash frequency:
approx. 1 Hz
Flash energy:
approx. 1 Ws
Starting current:
max. 2 A (Aud)/max. 4 A (Opt)
Colour:
red
Cable entry:
Diaphragm bushing; cable diameter max. 9 mm
Sound output:
98dB
Service life:
min. 4 million flashes (audible: min. 5,000 h)
Protection rating:
IP65
Voltage:
24V AC/DC
Voltage type:
AC/DC
Current consumption:
Opt.:max.120mA/aud.:max.80mA
Temperature range:
-20°C...+50°C
Tone type:
Contin. tone
Tone frequency:
ca. 110 Hz
Housing material:
PC/ABS-Blend
Lens:
PC
Signal effect:
Flashing
Diameter:
83 mm
Height:
234.5 mm
Depth:
91 mm
Net weight:
183 g
Total weight:
237 g
