NHVC Series Connectors Nanaboshi
Features
1. 1.Supply of electric power to hight-voltage electrical equipment for movement of a site of contractions, etc.
2.Supply of electric power to a high-Voltage, etc
3.Simplification of maintenance of high-Voltage electrical equipment, etc
•Material and Finish
1.Shall : - Material : Allumunium alloy
2.Insulator : - Materials : Synthenic resin
3. contact : - materials : Copper alloy
- Finish : Silver Plating
4.Packing : -Material : synthenic rubber
• Cable Termination : Soldering
•Operating temperature range : – 25°C to - 85°C
•Water resistance : Waterproof type
•Electrical Perfomance
1.NHVC-904 : - Rating : 3.3kV 80A
- Withstand Impluse Voltage : ±45kV or more
2.NHVC-904 : - Rating : 3.3V 200A
- Withstand Impluse Voltage : ±35kV or more
3.NHVC 1203 : - Rating : 6.6V 350A
- Withstand Impluse Voltage : ±80kV or more
