Han-Easy Lock®:
Yes
Locking cycles (with housings, bulkhead mounting):
>= 50
Locking cycles (split hood):
>= 10
RoHS conformity:
Please contact our customer service
Material, locking lever:
polycarbonate + stainless steel
Lever type:
double locking lever
Type of hood/housing:
Panel feed through housings
Limiting temperature, min.:
-40 °C
Limiting temperature, max.:
125 °C
Hint:
Please order cable entry glands separately.
Top
Material properties
Colour, locking element:
RAL 7037 (grey)
Material, hood/housing:
polycarbonate
Top
Dimensions and weight
Net Weight:
56.58 g
Top
Version
No. of cable entries:
4
Top
Norms and specifications
Flammability locking lever acc. to UL 94:
V 0
Protection class acc. to UL 50:
NEMA type 4/4X/12
Flammability hoods/housings acc. to UL 94:
V 0
Degree of protection acc. to DIN EN 60 529:
IP65
Top
Scope of delivery
Range of delivery:
2 split hood halves
