CONSTRUCTION & SPECIFICATIONS
– MATERIALS: CA36 ASTM B16 BRASS
– VALVES: RATED AT 600 WOG
– VALVE BODY: CAST BRONZE ASTM B584
– TAIL PIECE: CA-360 B-16
– BALL: BRASS CA-360 HARD CHROME P
– LATED SEALS: REINFORCED PTFE, 15%
– GLASS FILLED HANDLE: STEEL ASTM B633
W/ZINC PLATING
– BRASS FITTING: PIPE NIPPLE – B16 / 1/8” NEEDLE VALVE-B16 DISCONNECTS-B16
– ID TAG: CHAIN: BRASS
– TAG: ALUMINUM -3.21” THICK #200 MILL
– SET SCREW: STEEL ZINC PLATED
– HOSES: GOODYEAR 3/16” FREON CHARGING HOSES
WITH NYTRIEE CORE, POLYESTER BRAID
AND NYTRILE COVER WITH PVC
FOR ABRASION RESISTANCE.
METER DATA
CONSTRUCTION:ALUMINUM BODY
OPERATION:BUNA “N” DIAPHRAGM
ACCURACY:±2.0%
TEMPERATURE:200º F MAX 1500 PSI MAX
PRESSURE:3 LBS/EACH
APPROX. WEIGHT:4 1/2” DIAL STANDARD – 6” AVAILABLE
