Cylinder Regulator With Precision Flow Meter
MODEL 7700 SERIES
Features
- This two-stage type excels in durability, ensuring stable set
pressure and flow at all times even when used continuously.
- The precision needle valve with a linear flow curve permits reli-
able setting of arbitrary flow even in a small flow range.
- Precision setting for general industry and medical equipment,
especially for standard gases.
Standard Specifications
|
Specification pressure range |
Max. flow rate |
Pressure gauge: kPa |
Material |
|
|
kPa |
(/MIN) |
Primary side |
Secondary side |
|
|
19.6-196 |
20L |
0-24517 |
0-294 |
Brass, SUS316 |
