Aluminum flow meter EF Series
Based on the same meshing gear principle as the VSE Series VS and VHM the VSE EF ecoflow sensor measures viscous media, however as in-line-device.
The VSE EF ecoflow is an inexpensive alternative to the VS Series for measuring tasks with lower standards of technical characteristics such as accuracy, pressure, temperature, etc.
Performance data
- Flow range 0,05 up to 150 l/min
- Pressure range up to 200 bar
- Temperature range 0 up to 80°C
- Frequency range up to 1666,7 Hz
- Viscosity range 2 up to 10.000 cSt
Applications
- Oils
- Lubricants
- Printing inks
