Acrylic Resin Flow Meter
MODEL RK200 SERIES
This is a compact lightweight acrylic flow meter. Models with or without a valve are available. The integrated transparent acrylic panel structure permits easy reading of the flow. This model is ideal for air sampling equipment, medical equipment, and analyzers.
Features
- Compact design, T
- Low Price,
- Quick delivery
Standard Spesifications
|
Fluids |
Air |
|
|
Flow range |
0.04-0.5L/MIN 2.5-25L/MIN |
|
|
0.1-1L/MIN 5-50L/MIN |
||
|
0.4-5L/MIN 10-100L/MIN |
||
|
1-10L/MIN |
||
|
Accuracy |
FS±6% |
|
|
Connection |
Rc 1/4 |
|
|
Material |
Body |
Acrylic resin |
|
Joint |
Brass |
|
|
Sealing Material |
NBR |
|
|
Proof pressure |
0.7MPa |
|
|
Temperature resistance |
65℃ (MAX) |
|
